23.8Ton 8.4m³ Bulldozer HBXG SD7N
Crawler Bulldozer
SD7N crawler bulldozer is 230 horsepower track-type dozer with elevated sprocket, power shift drive, semi-rigid suspended and pilot hydraulic controls.
● Model: SD7N Bulldozer
● Brand Name: HBXG
● Operating Weight: 23800Kg
● Dozing Capacity: 8.4m³
● Flywheel output: 169KW/230HP
● Max.Digging Depth: 498mm
● Classification: Crawler Bulldozer
Specifications
| Engine | NT855-C280S10 |
| Flywheel output | 169KW/230HP |
| Operating weight | 23800Kg |
| Ground pressure | 71.9Kpa |
| Track gauge | 1980mm |
| Gradient | 30°/25° |
| Min. ground clearance | 404mm |
| Dozing capacity | 8.4 m³ |
| Max. Digging depth | 498mm |
| Overall dimensions | 5677×3500×3402mm |
Send Your Inquiry
To contact us please use the following form to submit your enquiry. We aim to contact you within one business day.
