21Ton 162kW/1950rpm Bulldozer SD20-C6
Medium-sized Bulldozer
The WP12 of bulldozer SD20-C6 electronically controlled engine conforms to the China-III non-road machinery emission regulation, featuring strong power, low fuel consumption, high intelligence and efficiency, high parts universality, and low maintenance cost.
● Model: SD20-C6 Bulldozer
● Brand Name: SHANTUI
● Operating Weight: 21,000kg (Standard)
● Engine Model: WP12
● Engine Power: 162kW/1950rpm
● Digging Depth(mm): 450mm
● Classification: Medium-sized Bulldozer
| Parameter name | Standard version |
| Performance parameters | |
| Operating weight (Kg) | 21000 (Including ripper) |
| Ground pressure (kPa) | 60.5 |
| Engine | |
| Engine model | WP12 |
| Rated power/rated speed (kW/rpm) | 162/1950 |
| Overall dimensions | |
| Overall dimensions of machine (mm) | 6805*3460*3305 |
| Driving performance | |
| Forward speed (km/h) | 0～3.9/6.8/10.6 |
| Reversing speed (km/h) | 0～5/8.6/13.4 |
| Chassis System | |
| Center distance of track (mm) | 1880 |
| Width of track shoes (mm) | 560 |
| Ground length（mm） | 2675 |
| Tank capacity | |
| Fuel tank (L) | 415 |
| Working device | |
| Blade type | Semi-U blade |
| Digging depth (mm) | 450 |
| Ripper type | Three-tooth ripper |
| Ripping depth (mm) | 595 |
