56Ton 380kW/1800rpm Bulldozer DH46-C3
Large-sized Bulldozer
Bulldozer DH46-C3's ECO mode in combination with the machine reduces the fuel consumption by approximately 15% compared with its Power mode.
● Model: DH46-C3 Bulldozer
● Brand Name: SHANTUI
● Operating Weight: 56000kg (Standard)
● Engine Model: QSX 15
● Engine Power: 380kW/1800rpm
● Digging Depth(mm): 660mm
● Classification: Large-sized Bulldozer
Specifications
| Parameter name | DH46-C3 RS |
| Performance parameters | |
| Operating weight (Kg) | 56000 |
| Ground pressure (kPa) | 120 |
| Engine | |
| Engine model | QSX 15 |
| Rated power/rated speed (kW/rpm) | 380/1800 |
| Overall dimensions | |
| Overall dimensions of machine (mm) | 9325*4320*3990 |
| Driving performance | |
| Forward speed (km/h) | F1: 0-11 |
| Reversing speed (km/h) | R1: 0-11 |
| Chassis System | |
| Center distance of track (mm) | 2260 |
| Width of track shoes (mm) | 610 |
| Ground length（mm） | 3532 |
| Tank capacity | |
| Fuel tank (L) | 920 |
| Working device | |
| Blade type | Semi-U |
| Digging depth (mm) | 660 |
| Ripper type | Single-shank ripper |
| Ripping depth (mm) | 1245 |
